The Bitmain Antminer S23 Hydro 3U is a powerful SHA-256 algorithm miner designed explicitly for Bitcoin (BTC) mining. It offers a maximum hash rate of 1160TH/s while consuming 11020W, with an energy efficiency of 9.5J/TH. It features an advanced water-cooling design to ensure efficient heat dissipation and consistent high performance, making it an ideal choice for enterprise-level mining operations.

The S23 Hydro 3U miner weighs approximately 18.2kg and is connected via an RJ45 Ethernet 10/100M interface, making it designed for heavy-duty infrastructure. Its optimal operating temperature range is 20℃ to 50℃, and it can be safely stored in an environment ranging from -20℃ to 70℃. The miner has a humidity resistance of 10% to 90% and is designed for demanding, high-yield mining environments.



Specifications:



Product Glance



Model



S23 Hyd 3U



Crypto algorithm/coins



SHA256|BTC/BCH/BSV



Typical hashrate



1.16PH/s



Power on wall @35℃



11020W



Power efficiency on wall@35℃



9.5J/th



Power Supply



Phase



3



Input voltage



380~415V



Input frequency range



50~60Hz



Input max current



12A



Hardware Configuration



Networking connection mode



RJ45 Ethernet 10/100M



Server size



900x486x132mm



Net weight



18.2kg



Environment Requirements



Inlet coolant temperature



20~50℃



Coolant flow



8.0~10.0L/min



Coolant pressure



≤3.5bar



Working coolant



Antifreeze / Pure water / Deionized water



Coolant pH value



Antifreeze: 7.0~9.0

Pure water: 6.5~7.5

Deionized water：8.5~9.5



Diameter of coolant pipe connector



Notice



Storage temperature



-20~70℃



Operation humidity(non-condensing)



10~90%RH
